At Yuhuan Hongqian Machinery Co., Ltd., we provide stainless steel water manifolds that deliver reliable fluid distribution for heating, cooling, and industrial systems. Made from high‑quality 304 stainless steel, these manifolds offer excellent corrosion resistance, structural strength, and long-term durability. Each unit is pressure-tested to ensure leak-free performance, providing consistent flow and reliability for a wide range of applications.
Premium 304 Stainless Steel Construction — Durable, corrosion-resistant, and suitable for long-term use.
Leak Tested — Factory pressure-tested to ensure reliable sealing and operation.
High Temperature Capability — Can handle up to 250 °F / 121 °C.
Multiple Port & Inlet Options — Flexible configurations to fit different system requirements.
Customizable Options — Supports optional valves, fittings, or gauges for tailored setups.
Mounting Brackets Included — Easy installation and stable support.
Robust welded construction with multiple ports. Available in standard inlet and port sizes.
Economical option with ports formed directly into the tubing for fixed installations.
Ball valves
Flow regulators
Pressure and temperature gauges
Custom port spacing or thread types
These options allow precise flow control and easy integration into your system.
Heating and cooling systems
Hydraulic fluid distribution
Industrial process water circuits
Chemical or high-temperature systems
Designed for demanding environments, our manifolds combine durable materials, precision manufacturing, and customizable options to provide reliable, leak-free performance for fluid distribution systems
| Technical Specification | Details |
|---|---|
| Material | 304 Stainless Steel |
| Design Type | Conventional & Low-Profile |
| Inlet/Outlet Size | 1″, 1½″, 2″ NPT/BSP |
| Port Size | ¼″, ⅜″, ½″, ¾″ NPT/BSP |
| Thread Type | NPT or BSP |
| Maximum Working Pressure | 250 psi (≈17.2 bar) |
| Maximum Operating Temperature | 250 °F (≈121 °C) |
| Corrosion Resistance | Excellent – suitable for water and chemical fluids |
| Testing | 100% Leak Tested |
| Optional Accessories | Valves, Flow Meters, Pressure Gauges |
| Applications | Plastic Injection Molding, Extrusion, Marine Systems, HVAC, Industrial Water Systems |
| Installation Notes | Low-Profile version ideal for space-constrained setups |
